Extreme Compute Power – Dual LGA 4677 sockets support up to 5th Gen Intel® Xeon® Scalable CPUs with 350W TDP each.
Massive High-Speed Storage – 12x Gen5 NVMe/SATA/SAS hot-swap bays, plus internal NVMe lanes from CPUs and PCIe switches.
GPU-Optimized Architecture – Supports 12x PCIe Gen5 x16 FHFL slots for high-performance GPU deployments (uniform models only).
Ultra-Efficient Power Supply – Redundant 3+1 CRPS 3000W PSU with 80 PLUS Titanium efficiency for enterprise-grade reliability.
Advanced Management & Monitoring – ASPEED AST2600 BMC with dedicated IPMI, full system monitoring, and BIOS-level remote access.
.png&w=3840&q=75)
Accelerating Artificial Intelligence and Leading Efficiency
Engineering richer features in a revolutionary platform, Intel has made an incredible jump in processor performance in the business transformation journey. AI and deep learning performance will benefit from the built-in AI acceleration engines, while networking, storage, and analytics leverage other specialized accelerators in the 4th & 5th Gen Intel Xeon Scalable processors. Adding a host of new features to target a wide range of workloads, the new families of Intel Xeon processors will deliver even better CPU performance and performance per watt, and do so on a PCIe 5.0 platform with 2x the prior gen throughput to greatly speed up data movement to and from GPUs and storage. Intel also created the Intel Xeon CPU Max Series with High Bandwidth Memory (HBM) for improvements in memory bound HPC and AI workloads. For this new platform, Hexadata has products ready to get the most out of Intel Xeon CPU-based systems that support fast PCIe Gen5 accelerators and Gen5 NVMedrives, in addition to support for high performant DDR5 memory.
Redefine Performance with 4th/5th Gen Intel Xeon Scalable Processors and Intel Xeon CPU Max Series
Accelerators
built-in*
Increase ROI while improving efficiency and performance
Up to 64
cores
More tasks can be done simultaneously and faster with dedicated cores
DDR5
support
Increased frequency and throughput with DDR5 RDIMM support
64GB
HBM**
High bandwidth in-package memory massively speeds up data-intensive workloads
PCIe 5.0
lanes
Increased I/O throughput achieving 128GB/s bandwidth with support for the latest drives and accelerators
CXL 1.1
support
Improve performance via memory coherency and direct accelerators memory access
* Different on-chip accelerators are supported depending on CPU SKUs and requires one-time activation. Please visit Intel's official website or contact technical support for details.
** HBM is an Intel Xeon CPU Max Series only feature. Please check the server specifications for more information on support for the Intel Xeon CPU Max Series.
Select Hexadata for the latest Gen Intel Xeon Platform
Support Server OS
Hexadata has validated platforms for compatibility with Windows Server, Ubuntu, and RHEL for greater manage ability and security
Ease of Management
Hexadata servers come with Hexadata Management Console for IPMI management.
Continuous Operation
Systems have RAS features for continuous uptime and availability as users require and expect stable performance around the clock .
Energy Efficient
Our engineers have created a highly eco-friendly entry level server platform for Intel Scalable Xeon with fanprofiles anda PSU with efficiency ≥ 89%.
Performance
The best in computational performance relies on a system well designed by our engineers to adequately dissipate heat to achieve peak performance.
Power Efficiency
Automatic Fan Speed Control
Hexadata servers are enabled with Automatic Fan SpeedControl to achievethe best cooling and power efficiency. Individual fan speeds will be automatically adjusted according to temperature sensors strategically placed in the servers.
Cold Redundancy
To take advantage of the fact that a PSU will run at greater power efficiency with a higher load, Hexadata has introduced a power management feature called Cold Redundancy for servers with N+1 power supplies. When the total system load falls lower than 40%, the system will automatically place one PSU into standby mode, resulting in a 10% improvement in efficiency.
Hardware Security
Optional TPM 2.0 Module
For hardware-based authentication, the passwords, encryption keys, and digital certificates are stored in a TPM module to prevent unwanted users from gaining access to your data. HexadataTPM modules come in either a Serial Peripheral Interface or Low Pin Countbus.
Hexadata Management Console
For management and maintenance of a server or a small cluster, users can use the Hexadata Management Console, which is preinstalled on each server. Once the servers are running, IT staff can perform real-time health monitoring and management on each server through the browser-based graphical user interface. In addition, the Hexadata Management Console also provides:
Certified Ready with Software Partners
Being a member of key software alliance partner programs enables Hexadata to rapidly develop and validate joint solutions, enabling our customers to modernize their data centers and implement IT infrastructure and application services with speed,agility, and cost optimization.
High Availability
SmartRideThrough(SmaRT)
To prevent server downtime and data loss as a result of loss of AC power, Hexadata implements SmaRT in all our server platforms. When such an event occurs, the system will throttle while maintaining availability and reducing power load. Capacitors within the power supply can supply power for 10-20ms, which is enough time to transition to a backup power source for continued operation.
Dual ROM Architecture
If the ROM that stores the BMC and BIOS fails to boot, the system will reboot with the backup BMC and/or BIOS replacing the primary. Once the primary BMC is updated, the ROM of the backup BMC will automatically update the backup through synchronization. For the BIOS, it can be updated based on user's choice of firmware version.
